730 EJ Articulated Truck
730 EJ Articulated Truck
The Cat 730 EJ with a 16.9 m³ (22.1 yd³)/27.1 tonnes (30 tons) capacity, offers demonstrated reliability and durability, high performance and productivity and a new world-class cab to improve operator comfort and ease of operation Updating the successful 730C2 EJ to include the new cab design makes the 730 EJ a more attractive proposition for our customers. Class leading levels of performance and new features such as Advanced Automatic Traction Control (AATC) and Assisted Ejecting Control create operator comfort, making a productive machine all day long. The machines retain all axle enclosed wet brakes and Advanced Productivity Electronic Control Strategy (APECS).
Engine Model
Cat® C13
Bore
5.1in
Stroke
6.2in
Displacement
763in³
Emissions
The 730 EJ meets Tier 4 Final and Stage V emission standards.
Note (4)
Net power when the fan is at maximum speed is 274 kW (367 hp) per the SAE reference conditions.
Note (3)
The net power advertised is the power available at the flywheel when the engine is equipped with alternator, air cleaner, muffler and fan at minimum speed.
Note (2)
The power ratings apply at rated speed of 1,800 rpm when tested under the conditions for the specified standard.
Note (1)
The references to Tier 4 Final/Stage V include U.S. EPA Tier 4 Final, EU Stage V, Japan 2014 (Tier 4 Final), and Korea Tier 4 Final emission standards.
Note (5)
DEF used in Cat SCR systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241-1. ISO 22241-1 requirements are met by many brands of DEF, including those that carry the AdBlue or API certificatio
Peak Engine Torque Net (ISO 14396)
1564ft·lbf
No Engine De-rating Below
12500ft
Engine Model - U.S. EPA Tier 4 Final/EU Stage V
Cat C13
Peak Engine Torque Speed
1200r/min
Net Power - SAE J1349:2011
367hp
Gross Power - SAE J1995:2014
375hp
Peak Engine Torque Gross (SAE J1995)
1579ft·lbf
Net Power - ISO 14396
370hp
-
- Note
-
- Standard and optional equipment may vary. Consult your Cat dealer for details.
- Engine block heater
- Cold weather start attachment
- Cat Production Measurement payload monitoring system
- Fast fuel fill
- Cold weather coolant –51° C (–60° F)
- Exhaust heated body
- Ether start
- Bluetooth radio stereo system
- Auto lube installation for automatic greasing of bearings
- Flashing LED beacon
- Four-point seat belt
- Fuel additive – anti-waxing
- Heated rearview motorized mirrors
- Machine Security System (MSS)
- Product Link Elite: PLE631 (satellite), PLE641 (cellular)
- Roof mounted High Intensity Discharge (HID) work lights
- Sound suppression (only standard in Europe)
- Heated/cooled seat
- Infrared glass – high ambient cab
- Window blinds
- Wheel chocks
